Welded Heat Exchanger

Plate and shell heat exchangers (PSHE) combine the pressure and temperature capabilities of a cylindrical shell with the excellent heat transfer performance of a plate heat exchanger. The round plates ensure an even distribution of mechanical loads, without the stress concentrations that occur in the corners of rectangular plates.

The design of the plate and shell heat exchanger is similar to that of a radiator or water heater, but it differs in that the water passes through two separate circuits—one for heating and one for cooling.

Plate and shell heat exchangers are a compelling choice for a variety of applications due to their impressive combination of features. Their design, utilizing stacked plates within a compact round shell, allows them to fit comfortably in tight spaces. Despite their size, these heat exchangers excel at transferring heat rapidly thanks to the design of the plates themselves. Moreover, they can handle high pressure and heat loads, making them suitable for demanding situations.

Compact

Small installation and surface area due to compact design.

Performance

High performance with small surface area, weight and footprint by high heat transfer coefficients – reducing structural steelwork and facilitating skid assembly

Fully Welded

Fully welded design eliminates gaskets, ensuring high temperature resistance and high reliability to failure and leakages.

Cost Effective

Low cost for steel structures and foundations due to low equipment weight and smaller footprint.

Reduced Fouling

Plate design provides a high wall shear stress, which acts as a self-cleaning effect – reducing fouling and extending the time between cleaning.

Flexible

Range of plate and nozzle sizes, combined with flexibility of shell design and number of nozzles provides optimised solution.

Working Principle

The gaps between the corrugated plates are forming flow channels which are flowed through alternately by a primary and secondary media. Flow directors at shell side prevent a bypass – flow between shell and plate pack. The flow direction of both media can be arranged as counter-flow, co-current or cross-flow. The heat is transferred via the corrugated plates. When one or both media are evaporating or condensing partly or completely, it is called a two-phase application.

By means of deflections the media at plate side and shell side as well can be led in multi passes. This way the thermal length is increasing. Our plate & shell heat exchangers are available in five sizes and with different corrugation patterns, i. e. with different corrugation angles and pressing depths.

H-plates allow high heat transfer rates caused by a high turbulent flow. L-plates are used in applications which are optimised for a minimal pressure loss. In gas / gas – applications or when the media is contaminated with solids G-plates often are used, which have larger channel cross-sections.

  • Operating temperature: -200 to 500 °C
  • Operating pressure: -1 to 400 bar (g)
  • Liquid hold-up varies from 3 to 1,000 litres per pressure chamber.
  • Dynamic viscosity up to 8,000 mPa s
  • Flexible shell design
  • Plate thickness from 0.6 to 1.25 mm with H-, L- or G- plates.
  • Weld thickness up to 3.5x higher than plate thickness.
  • Plate design with self-cleaning effect.
  • Wide range of plate materials provides high corrosion resistance.
  • Nozzle sizes: DN 20 (3/4“) to DN 1000 (40”).

Counter Flow

The most common form of flow configuration.

Cross Flow

For a reduced resistance on the primary and secondary side.

Co-current Flow

For maximum temperature differences at the inlet, or to avoid temperature crossing.

Inlet and outlet on both ends

For large volumetric flows on the plate side.

Plate side deflection

For large differences in volumetric flow rates between plate and shell side.

Shell and Plate side deflection

For optimising the pressure loss and heat transfer on both sides.

Plates with H-, L- and G- corrugation.

H-plates allow high heat transfer rates caused by a high turbulent flow. L-plates are used in applications which are optimised for a minimal pressure loss, or hydraulically limited.

In gas / gas – applications or when the media is contaminated with solids G-plates are often used, which has a larger cross-sectional area.

Air cooler, openable, with condensate separation

Gas cooler, cross-flow

Refrigerant evaporator, with steam dome

Fully-welded HE, for liquid-liquid applications
