FLOMAC® Progressive Cavity Pump In Malaysia

Progressive cavity pump is also known as PC Pump (PCP), single screw pump or more commonly called by some as Mono pump. Our FLOMAC progressive cavity pump have a wide range of industrial applications including edible oil, latex industry, oil and gas, wastewater treatment and many others. From sludge, slurry, chemical liquid to food product, FLOMAC pumps would have a suitable model for you.

Structure

Simple structure, easy maintenance and robust design allow for ease of maintenance.

Strong Suction

Strong suction capability with suction lift up to 8m. Our pump design has low NPSHr.

Efficient

High efficiency with volumetric efficiency up to 96%. Mechanical efficiency 70 – 80%.

Viscosity

Able to handle abrasive liquid & viscosity up to 1,000,000 cPs .

Solids

Liquid with solid content up to 45% – 70% depending on type and size.

Flow

Pulsation free with low noise and continuous flow operation.

Pump Structure

Working Principle

Progressive cavity pump (PCP) belongs to the group of positive displacement pump. It transfers fluid by means of the progress, through the pump, of a sequence of small, fixed shape, discrete cavities, as its rotor is turned. The cavities taper down toward their ends and overlap. As one cavity diminishes another increases, the net flow amount has minimal variation as the total displacement is equal. This design results in a flow with little to no pulse.

The media within the seal cavities will be conveyed from the entry end to the exit end of the pump, and the conveying process of the pump is thus realised.

Features

  • Flowrate from 0.02 m3/hr up to 350 m3/hr

  • Working pressure up to 72 bar

  • Solid content up to 70%

  • Viscosity up to 1,000,000 cPs

  • Able to pump fibrous media

  • Pulsation free flow

  • Strong suction up to 8m

  • Low NPSHr

  • Low vibration and noise emission

  • Consistent flow with each rotation. Suitable for metering application.

  • Pump is bidirectional. Inlet can become outlet and vice versa.

Contact us to find out more

GET A FREE QUOTE

Pump Types

Closed Coupled

Pump shaft is directly driven, compact structure and shorter in length.

  • Capacity (max) : 600 m3/hr
  • Pressure (max) : 24 bar or higher

Compact

Motor is installed above the pump and is driven via belt and pulley, hence shorter structure.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Hopper

Pump housing with hopper design suitable for high viscosity and high solid content medium.

  • Capacity (max) : 100 m3/hr
  • Pressure (max) : 48 bar or higher

Vertical

Designed with bracket hoist or mounting plate for vertical installations. Ideal for high negative suction applications.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Vertical length of installation can be designed according to requirement

Bearing Pedestal

Pump is driven through bearing pedestal; strong load-bearing ability, good rigidity.

  • Capacity (max) : 600 m3/hr
  • Pressure (max) : 48 bar or higher

Metering

Dosing chemical or liquid with adjustable speed and high accuracy.

  • Capacity (min) : 0.03 L/min
  • Pressure (max) : 24 bar or higher
  • Metering Accuracy : ± 1%

Hygienic

Designed for food & pharmaceutical application with surface polishing.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Customized Designs

We can incorporate any customized design according to your application needs.

Pump Types

Closed Coupled

Pump shaft is directly driven, compact structure and shorter in length.

  • Capacity (max) : 600 m3/hr
  • Pressure (max) : 24 bar or higher

Compact

Motor is installed above the pump and is driven via belt and pulley, hence shorter structure.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Hopper

Pump housing with hopper design suitable for high viscosity and high solid content medium.

  • Capacity (max) : 100 m3/hr
  • Pressure (max) : 48 bar or higher

Vertical

Designed with bracket hoist or mounting plate for vertical installations. Ideal for high negative suction applications.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Vertical length of installation can be designed according to requirement

Bearing Pedestal

Pump is driven through bearing pedestal; strong load-bearing ability, good rigidity.

  • Capacity (max) : 600 m3/hr
  • Pressure (max) : 48 bar or higher

Metering

Dosing chemical or liquid with adjustable speed and high accuracy.

  • Capacity (min) : 0.03 L/min
  • Pressure (max) : 24 bar or higher
  • Metering Accuracy : ± 1%

Hygienic

Designed for food & pharmaceutical application with surface polishing.

  • Capacity (max) : 200 m3/hr
  • Pressure (max) : 24 bar or higher

Customized Designs

We can incorporate any customized design according to your application needs.

Other Pump Designs

Pump Skid Design

Barrel Pumping System

Hopper with Bridge-Breaker

Compact Design Hopper Pump

Horizontal Compact Variant
